Description Calcium and Magnesium Analyser | Antojn Bruckner Technical Specifications SYSTEM INFORMATION Measurement variable Calcium and Magnesium Measurement application Drinking water | Industrial Water Measurement ranges 0-100 mmol Accuracy and Precision < 3 % (based on full scale) Resolution Same as precision values Calibration and cleaning Automated Seibold Reagent kit HNB/EDTA. MEASUREMENT INFORMATION Measurement method Spectro-Photometer. Peak at 570nm. Measurement interval Continuous; Discontinuous (programmable, external start) Sample and Reagents consumption per measurement Sample: ~ 75 – 200 ml Reagent: ~ 3 ml ENVIRONMENTAL DATA Ambient operating temperature, sample temperature: 5 to 40°C Ambient operating humidity: Up to 95 % RH non-condensing (below the condensation limit) ELECTRICAL DATA Power supply Supply voltage: 220 – 230 V AC, 50 – 60 Hz (110 V AC or 24 V DC, optional) Power consumption: Approx 50 VA Output signal: 4 – 20 mA Screen Color | TFT | Liquid Crystal Display (LCD) with built-in backlight and brightness adjustment. MAINTENANCE Maintenance interval: 3 months Calcium and Magnesium Analyser | Antojn Bruckner
